Jabsco 18680-0920 light duty vane pump operates by the rotary sliding vane principle, with Vectra rotor and vanes designed to handle oil or diesel fuel transfer. Pumps up to 6.2 gallons per minute and transfers diesel fuel from a 55 gallon drum in 10 minutes. Self-priming to 3 feet. Quiet. Low amp draw. Vane pumps are equipped with a high torque motor with ball type shaft bearings and are rated for continuous duty operation. The bronze pump has ports with 1/2" internal pipe thread and 1" external hose barb. Also supplied are port adapters for 3/4" garden hose thread.

Features

• Fuel or oil transfer pump
• Pumps up to 6.2 gpm
• Self-priming to 3 ft.

Specifications

• Dimensions: 3-3/8" H x 4-3/4" W x 7-1/8" L
• Volt: 12V DC
• Amp Draw: 8 amp

Ports

• Interior: 1/2" NPT
• Exterior: 1" hose
